Large Diameter,Smooth Stroke Piston
Efficient Valve chest for low maintenance rates
Drop-Forged cylinder
Chisel retainer spring included;
Model | Blows Per Minute(BPM) | AVERAGE AIR CONSUMPTION(25%) SCFM | Impact Energy | Sound dBA(pressure/Power) | Piston Stroke | EXHAUST | LENGTH | WEIGHT | AIR PRESSURE | AIR INLET | ||||||
J/M | Kg-cm/cm | Ft-lb/in | In. | m/m | m/m | in | kgs | lbs | psi | kg/c㎡ | ||||||
BW-PH05 | 1,060 | 55 | 45 | 441 | 0.85 | N/A | 6.1 | 155 | Handle | 570 | 22.4 | 10 | 22 | 90 | 6.3 | 5/8 |
BW-PH06 | 1,060 | 59 | 55 | 539 | 1.03 | N/A | 6.1 | 155 | Handle | 580 | 22.83 | 14 | 30.8 | 90 | 6.3 | 3/4 |
BW-PH07 | 1,060 | 59 | 55 | 539 | 1.03 | N/A | 6.1 | 155 | Handle | 640 | 25.2 | 22 | 48.4 | 90 | 6.3 | 3/4 |
